Saturn Evolution Birch-Walnut
First introduced as a special edition in 2012, the Birch/Walnut hybrid shell has made its return to the Saturn Evolution line with Design Lab features. The new shell formula perfectly combines the sonic characteristics of walnut with articulate punch of birch, delivering a Dark, Punchy, Dry sound.
Saturn Evolution Birch-Walnut
-
SE628XB Workhorse Birch 5-Pc Shell Pack
-
SE529XB Rock Birch 4-Pc Shell Pack
-
SE529XEB Classic Birch 4-Pc Shell Pack
-
SE504XB Fusion Maple 4-Pc Shell Pack
-
Exotic Aegean Fade Lacquer (OE)
-
Exotic Night Forest Burst Lacquer (MZ)
-
Tuscan Red Lacquer (PA)
-
Gun Metal Grey Lacquer (PG)
-
Piano Black Lacquer (PB)
-
Exotic Azure Burst Lacquer (PT)
-
Tuscan Yellow Lacquer (PM) *Special Order
-
Iridium Silver Lacquer (PD)
-
Polar White Lacquer (PI)
-
Exotic Violet Burst Lacquer (PZ)
-
Brunswick Green Lacquer (PQ)
-
Exotic Sunburst Lacquer (PO)
SAS (SONIClear Attenuation System) Finish
The Natural Satin SAS Finish brings out the beautiful character of the woods used in the drums but also allows the shell to vibrate fully due to its extremely low-mass application. Thicker finishes like high-gloss add mass to the shell and shorten sustain. Future Design Lab models may employ a thicker finish to create a more focused sound.
FEATURES
Halo Mounting System
The revolutionary new "Halo" mount featured on all Saturn Evolution toms, unlocks the freedom of full resonance. Using a lateral, unique "under lug-line" suspension system, this new groundbreaking isolation mount allows the shell the freedom to have an open, pure tone. This is done with minimal stiffness usually associated with under hoop mounting systems.
Adjustment Knob
With the rubber gasket inside the mount, you can screw the knob down fully to dampen the shell resonance for a shorter decay, or back it off for a wide, open tone. In the studio, this allows you to "pre-EQ" your drums before feeding them into your plug-ins.
Birch/Walnut Hybrid Shell
First introduced as a special edition in 2012, the Birch/Walnut hybrid shell has made its return to the Saturn Evolution line with Design Lab features. The new shell formula perfectly combines the sonic characteristics of walnut with articulate punch of birch, delivering a Dark, Punchy, Dry sound.
Chamber Specific Design
Plies get progressively thicker, depths graduate by 1/2”, and bearing edges change as the drums get larger in diameter. The combination of all of these details creates an amazing symphony in one kit, where each and every drum sounds perfect!
SPECIFICATIONS
Saturn Evolution | |
---|---|
Mounting System | Halo Mounting System |
Shell | Birch and Walnut Hybrid Shell |
SAS 0-1 (PD, PM, PA, PG, PQ, PI, PB) | Toms (8", 10"): 6-Ply, 5.8mm Toms (12", 13", 14"), and Floor Toms (14", 16", 18"): 6-Ply, 6.5mm Bass Drum: 8-Ply, 8.2mm |
SAS 2 (MZ, OE, PO, PT, PZ) | Toms (8", 10"): 7-Ply, 6.15mm Toms (12", 13", 14"), and Floor Toms (14", 16", 18"): 7-Ply, 6.85mm Bass Drum: 9-Ply, 8.55mm |
Hardware | Chrome / Black Brushed Hardware |
Hoops | Mapex Sonic Saver Hoops |
Mapex SONIClear™ Bearing Edge: | 45° on Toms, and Floor Toms 60° on Bass Drum |
Air Flow Venting | 2 Vent Holes on Toms and Floor Toms 4 Vent Holes on Bass Drum |
Floor Tom Legs | SAS Static 90 Degree Floor Tom Legs Sonic Pedestal Floor Tom Feet |
Components | ||
---|---|---|
Bass Drum | SEB1814B | 18" x 14", with bass drum mount |
SEB1814BA | 18" x 14", without bass drum mount | |
SEB2014B | 20" x 14", with bass drum mount | |
SEB2016B | 20" x 16", with bass drum mount | |
SEB2016BA | 20" x 16", without bass drum mount | |
SEB2018BA | 20" x 18", without bass drum mount | |
SEB2216BA | 22" x 16", without bass drum mount | |
SEB2218BA | 22" x 18", without bass drum mount | |
SEB2414BA | 24" x 14", without bass drum mount | |
SEGB1816B | 18" x 16" Gong Bass | |
Floor Tom | SEF1412B | 14" x 12" |
SEF1414B | 14" x 14" | |
SEF1614B | 16" x 14" | |
SEF1616B | 16" x 16" | |
SEF1816B | 18" x 16" | |
Toms | SET807B | 8" x 7" |
SET1007B | 10" x 7" | |
SET1008B | 10" x 8" | |
SET1208B | 12" x 8" | |
SET1209B | 12" x 9" | |
SET1309B | 13" x 9" | |
SET1310B | 13" x 10" | |
SET1410B | 14" x 10" | |
SET1411B | 14" x 11" |
Components
Saturn Evolution
Model No. | Size |
---|---|
SEB1814M | 18 x 14, w/ BD mount |
SEB1814B | 18 x 14, w/ BD mount |
SEB1814MA | 18 x 14, no BD mount |
SEB1814BA | 18 x 14, no BD mount |
SEB2014M | 20 x 14, w/ BD mount |
SEB2014B | 20 x 14, w/ BD mount |
SEB2016M | 20 x 16, w/ BD mount |
SEB2016B | 20 x 16, w/ BD mount |
SEB2016MA | 20 x 16, no BD mount |
SEB2016BA | 20 x 16, no BD mount |
SEB2018MA | 20 x 18, no BD mount |
SEB2018BA | 20 x 18, no BD mount |
SEB2216MA | 22 x 16, no BD mount |
SEB2216BA | 22 x 16, no BD mount |
SEB2218MA | 22 x 18, no BD mount |
SEB2218BA | 22 x 18, no BD mount |
SEB2414MA | 24 x 14, no BD mount |
SEB2414BA | 24 x 14, no BD mount |
SEGB1816M | 18 x 16 Gong Bass |
SEGB1816B | 18 x 16 Gong Bass |
Model No. | Size |
---|---|
SEF1412M | 14 x 12 |
SEF1412B | 14 x 12 |
SEF1414M | 14 x 14 |
SEF1414B | 14 x 14 |
SEF1614M | 16 x 14 |
SEF1614B | 16 x 14 |
SEF1616M | 16 x 16 |
SEF1616B | 16 x 16 |
SEF1816M | 18 x 16 |
SEF1816B | 18 x 16 |
Model No. | Size |
---|---|
SET807M | 8 x 7 |
SET807B | 8 x 7 |
SET1007M | 10 x 7 |
SET1007B | 10 x 7 |
SET1008M | 10 x 8 |
SET1008B | 10 x 8 |
SET1208M | 12 x 8 |
SET1208B | 12 x 8 |
SET1209M | 12 x 9 |
SET1209B | 12 x 9 |
SET1309M | 13 x 9 |
SET1309B | 13 x 9 |
SET1310M | 13 x 10 |
SET1310B | 13 x 10 |
SET1410M | 14 x 10 |
SET1410B | 14 x 10 |
SET1411M | 14 x 11 |
SET1411B | 14 x 11 |
Model No. | Size |
---|---|
SES4650M | 14 x 6.5 |
SES4600B | 14 x 6 |
